    Interne referentie: DTS-03.MW010
    Technische Fiche:

    ALCHEMY 3

    The new-generation HQS LED wash light
    that combine high luminosity with superior light quality

    Highlights

    6-color LED source with Ø 175 mm Fresnel lens

    14.1° - 45.2° linear zoom

    high luminosity with an evenly diffused and flat beam

    superior white light quality
    and accurate color rendering

    extended color palette

    wide gamut of pastel-like colors

    linear CCT to meet camera
    or production requests

    Silent mode for theatres and TV studios

    'Hi-Q Dimming' technology

    Green – Magenta linear balance,
    for a natural reproduction of any skin tone

    Technical data

    ALCHEMY 3 is a very compact high performance Fresnel LED wash moving head made for medium to small theatres and television studios. The unit is able to deliver an outstanding light quality coupled with a high luminosity.
    ALCHEMY 3 bears the ‘HQS’ (High quality Spectrum) mark which identifies the ability to generate a superior white light and a broad color gamut with pastel shades and rich warm nuances. Also ALCHEMY 3’ ‘Silent’ mode matches theatre and television standards, where quietness is a key factor.


    Output

    • Multi-chip LED source

    • 6,600 Lumen output

    • CRI: up to 98

    • TLCI: up to 96

    • LED lifespan: 20,000 hours (70% lumen output)

    Optical group

    • 14.1°- 45.2° linear zoom

    • Ø 175 mm Fresnel lens

    • Beam shaper (2x1 ratio) with endless rotation; indexable

    • Heavy frost filter insertable via DMX

    • Retractable ‘top hat’

    White and Color generation

    • Linear CCT (1800 K - 10000 K)

    • Green saturation: Linearly adjustable green/magenta point

    • 100 gel filters emulation- Linear crossfade from gel filters emulation to CCT whites
    - Linear crossfade between emulated gel filters
    - True color of gel filters emulation at any CCT values

    • “Raw” RGBACL color-mixing in ‘Advanced’ mode

    • Extra deep colors: Two DMX-selectable filters (‘deeper blue’ and ‘deep red’) allow to further extend the range of reproducible colors toward the two ends of the visible spectrum

    • HQS (High Quality Spectrum) - DTS’ trademark certifies a product’ superior white light quality and its ability to generate an extended color palette offering a wider gamut of pastel shades with rich warm nuances.

    Dimmer

    • ‘Hi-Q Dimming’ technology – guarantees a perfect linearity in the increase / attenuation of brightness of multi-chip LED sources, even at low dimming levels, without visible ‘steps’ between adjacent values

    • Tungsten emulation - CCT variation emulates behavior of Halo-lamps

    Control

    • LCD graphic display + 4 soft-keys; Auto-flip; Key-Lock function

    • RDM / DMX 512 protocol

    • Wireless DMX available on request

    • Art-Net 4, sACN protocols available on request

    • ‘Standard’ and ‘Silent’ operation modes

    • Internal operating system updatable via DTS dongle firmware uploader

    • “Li-Fe” backup battery allows the use of the unit’s on-board display when it is not powered, besides ensuring a safe return and blockage of the top hat during shut down

    DMX

    • 5 DMX modes:
    - 1. CCT (default)
    - 2. Advanced
    - 3. Basic
    - 4. Expo
    - 5. CMY Emulation

    Pan & Tilt

    • Pan 540° :1.8 s

    • Tilt 215° : 1.1 s

    • 16-bit resolution


    Power supply

    • Wide-range 100-240Vac 50-60 Hz
    • Power consumption: 300 W max
    • Power Factor: PF >0.94

    Connections

    • Power supply: PowerCON TRUE1 In/Out panel connectors

    • DMX: XLR 3-pole and 5-pole In/Out panel connectors

    Circuits protections

    Overvoltage and overtemperature circuits protection

    Operating temperature

    -10° / 40° C

    Physical

    • IP20
    • Weight: 15.5 Kg (34 lbs)
    • Finishing: Black

    Accessories included

    • 1 x PowerCON TRUE1 female connector (code 0520P066)

    • 1 x Omega bracket with “Fast Lock” (code 02K00467)

    Accessories on request

    • Aliscaf clamp for tube diameter 48-51 mm - max. load. 200 Kg (code 0521A033)

    • G-QUICK clamp Professional - max. load 100 Kg (code 0521A037)

    • Outdoor DMX cable 2 x 0,25 mm2 - Flame retardant (code 0509C158)

    • Safety cable 3 x 600 mm - Max load 30 Kg (code 0521A010)

    • DTS firmware uploader dongle (code 03.LA.206)
